iSensor i8 Connector Specifications

Download iCONN Systems' Free Shielded Cables & Connectors Whitepaper
Request a Quote Today
Materials:

Contact Carrier
Mineral Filled PA
Coupling Nut
Nickel Plated Brass or Stainless Steel
Panel Mount Housing
Nickel Plated Brass or Stainless Steel
Jam Nut
Nickel Plated Brass or Stainless Steel
Mounting Gasket/O-ring
Buna
Contacts
Cu Alloy, Gold over Nickel Plating
Plug O-Ring
Silicone
Overmold
Overmold material will vary depending on cable selection (PVC, TPU, or other)



Dimensions:

Receptacle Mounting OD
M8 Thrd
Basic Plug Max OD
.39" DIA. Over Coupling Nut
In-Line Receptacle OD
.39" DIA. Over Coupling Nut
Overmold Length w/ Strain Relief
1.07"
Max Cable Diameter
.2" DIA.
Contact Sizes Available
20 and 23 AWG



Performance:

Ingress Protection
IP67
Max Continuous Temperature
Overmold material and wire/cable selection will influence the overall max temperature rating of the assembly (80 - 105 degrees C)
