What is a Pull Force Test?
Understanding the Pull Test Procedure
iCONN performs pull testing in-house to determine if the tension and breaking strength specifications have been met per regulation or contract. Temperature rise validation testing is done to ensure UL over 30 degrees Celsius is met over ambient temperature requirements.
.png?width=293&name=BuyersGuide%20(1).png "Buyers Guide")
Find the right connector for your project. Get our Buyer’s Guide today.
Pull Force Testing at iCONN
In this video, iCONN Systems tests one of its cable assemblies by challenging its strength. Watch as 500 pounds of weight pull at the connector without affecting its performance.
The pull test verifies that the connector/cable assembly can withstand abuse. In this test, a custom connector that needed to survive in applications is used. The cable assembly must be able to pull up a device that weighs up to 300 points. iCONN designs cables with strength members that attach to connector ends to help with these applications. It designs the coupling mechanisms to have enough material to withstand extremely heavy weight.
The test shown is a straight pull test with a consistent load.
